NSSDC: Voyager Project Information

Voyager Project Information

Not fare well,
But fare forward, Voyagers.
-- T. S. Eliot, The Dry Salvages

New! A new satellite has been discovered orbiting Uranus. The discovery was made from images returned in 1986 by the Voyager 2 spacecraft. It is the 18^th known satellite of Uranus. For more information see the NASA Press Release.

Launch Date:	September 5, 1977 (Voyager 1)
	August 20, 1977 (Voyager 2)
Launch Vehicle:	Titan III E-Centaur
On-orbit mass:	721.9 Kg
Power System:	Radioisotope Thermal Generators (RTGs) of 420 W

The last two spacecraft of NASA's Mariner series, Voyager 1 and 2 were the first in that series to be sent to explore the outer solar system. Preceeded by the Pioneer 10 and 11 missions, Voyager 1 and 2 were to make studies of Jupiter and Saturn, their satellites, and their magnetospheres as well as studies of the interplanetary medium. An option designed into the Voyager 2 trajectory, and ultimately exercised, would direct it toward Uranus and Neptune to perform similar studies.

Although launched sixteen days after Voyager 2, Voyager 1's trajectory was a faster path, arriving at Jupiter in March of 1979. Voyager 2 arrived about four months later in July 1979. Both spacecraft were then directed on to Saturn with arrival times in November 1980 (Voyager 1) and August 1981 (Voyager 2). Voyager 2 was then diverted to the remaining gas giants, Uranus (January 1986) and Neptune (August 1989). A more detailed table specifying the closest approach distances/times for these encounters is available.

Data collected by Voyager 1 and 2 were not confined to the periods surrounding encounters with the outer gas giants, with the various fields and particles experiments and the ultraviolet spectrometer collecting data nearly continuously during the interplanetary cruise phases of the mission. Data collection continues as the recently renamed Voyager Interstellar Mission searches for the edge of the solar wind's influence (the heliopause) and exits the solar system.

Some scientific results of the Voyager mission

A comprehensive list of the achievements of Voyager 1 and 2 would be so extensive that space doesn't permit. Here, then, are a (very) few results that would rank near the top of many such lists.

Discovery of the Uranian and Neptunian magnetospheres, both of them highly inclined and offset from the planets' rotational axes, suggesting their sources are significantly different from other magnetospheres.
The Voyagers found 22 new satellites: 3 at Jupiter, 3 at Saturn, 10 at Uranus, and 6 at Neptune.
Io was found to have active volcanism, the only solar system body other than the Earth to be so confirmed. Triton was found to have active geyser-like structures and an atmosphere.
Auroral zones were discovered at Jupiter, Saturn, and Neptune.
Jupiter was found to have rings. Saturn's rings were found to contain spokes in the B-ring and a braided structure in the F-ring. Two new rings were discovered at Uranus and Neptune's rings, originally thought to be only ring arcs, were found to be complete, albeit composed of fine material.
At Neptune, originally thought to be too cold to support such atmospheric disturbances, large-scale storms (notably the Great Dark Spot) were discovered.

Additional information about Voyager 1
Information about Voyager 1 experiments
Information about Voyager 1 data sets
Additional information about Voyager 2
Information about Voyager 2 experiments
Information about Voyager 2 data sets

Other Voyager Information/Data at NSSDC

Go to the NSSDC Voyager page

Read about and/or order the Voyager imaging CD-ROM set
Read about and/or order the Outer Planets Fields and Particles CD-ROM set

COHOWeb (Browse and retrieve Voyager cruise magnetic field and plasma data)
SPyCAT/NDADS (Retrieve Voyager cruise magnetic field data)
Retrieve COHO data from NSSDC's anonymous FTP site

Obtain Voyager 1/2 position data (heliographic coordinates)

View some of the images in the NSSDC Photo Gallery taken by Voyager of:
